  1. As per Vehicle Inspectors Bulletin 52 that came into effect November 2007 and is still in force that any recognized engineering signatories, Blue or Pink slip stations of the circumstances in which light vehicles are exempt from registration provisions when being driven for the purposes of obtaining registration. vib-52-exemption-registration-lightvehicle.pdf
  2. Version 1.0.0

    0 downloads

    Daytime running lamps rules as per the ADR's

    Free

  3. Version 1.0.0

    0 downloads

    This checklist outlines procedures and minimum requirements for testing noise emissions of motor vehicles using stationary noise tests. It applies to both modified and individually constructed vehicles

    Free

  4. Version 1.0.0

    0 downloads

    This modification code covers the installation of non original equipment engines with not more than 20% greater mass and/or power output than engines offered by the vehicle’s first manufacturer as a standard or optional engine. Code LA1 does not apply to ADR category L-Group vehicles and motorcycles. MODIFICATIONS COVERED UNDER CODE LA1 The following modifications may be performed under Code LA1: Fitting of a replacement engine with not more than 20% greater mass and/or power output than engines offered by the first manufacturer as a standard or optional engine. MODIFICATIONS NOT COVERED UNDER CODE LA1 The following is a summary of the modifications that may not be performed under Code LA1: Fitting of a replacement engine that does not comply with the applicable ADRs; Fitting of a replacement engine of which the specifications are not suitable for use with the existing components of the vehicle; and Fitting of a replacement engine that necessitates substantial modification to the vehicle’s structure (e.g. firewall, chassis modifications) or where any structural changes compromise the vehicle’s ability to continue to comply with the occupant protection ADRs.

    Free

  5. Version 1.0.0

    0 downloads

    This checklist is called up by Code LO1 of Section LO Vehicle Standards Compliance and is intended to assist. The checklist applies to Second Edition ADR category vehicles only.

    Free

  6. AIS and AUVIS Inspections fees for all pink and blue slip funtions Link click here
  7. Version 1.0.0

    4 downloads

    Orthographic and Isometric Projection's are a way of drawing an 3D object from different directions in 2D. Usually a front, side and top view are drawn so that a person looking at the drawing can see all the important sides. Orthographic drawings are more useful then Isometric as they are a global standard for manufacturing and Engineering this PDF booklet explains in depth how to make a Orthographic Projection's

    Free

  8. Mark Dewhurst Automotive Engineering offers an Independent Expert Reporting service where you vehicle can be inspected and tested and a report will be created that can be used for Legal, Insurance or Warranty purposes. Information contained in the Report document consists of both Expert opinions of the report creator Mark Dewhurst and documented proof that will be attached to the report where it is needed as well as a list of my qualifications this service isn't free and is charged out at $175 per hour with specific test's will incur different cost's. you can become a member by clicking on the " new user signup " button at the top right of this page or by clicking on the gold " Independent Expert Report " button below that will open a new page on the store where you can purchasing the Independent Expert Report product. please note that becoming a member through the store is a instant automated process where manual signups need to be approved and can tack a couple of days. the Independent Expert Report Fee is a Non refundable application fee for beginning the reporting process ,includes access to secure section of the website and one on one guidance through the process. This application fee is marked as part payment for the final invoice After payment or account set up is completed a new section on the main website page will be viewable,a screenshot can be seen at the bottom of this page showing the secure area outlined in dark blue. start in the " Consultant Service " section. this link in blue wont work until your a member. for over the phone payments or if you are having any other problem submitting please call 0438572405 in business hours or start a support request at the below link a downloadable sample of what your report could look like is available at the below link Click Here to download the sample
  9. Please note that this Document looks very different in its original form to view the correct format download the document at the download link at the bottom of this page. Inspection Report 004764 VE commodore Mark Dewhurst Mark Dewhurst Automotive Engeneering | 0438572405 5 Koolera Road Wyee NSW 2259 www.markdewhurst.com Inspection Report 004764 VE Commodore VIN= XXXXXXXXXXXXXXXX Scope of Document This Document is prepared at the request of the client and is accurate at the time it was created It can be used as a detailed report for Legal, Insurance or Warranty purposes Information contained in this document consists of both Expert opinions of the report creator Mark Dewhurst and documented proof that will be attached to this report where it is needed Client Information Client Name xxxx xxxxxxx Client Email xxxxx@gmail.com Vehicle Make and Model Holden Commodore Year of Manufacture 2009 Registration Number XXXXXX Inspection Reference 004764 Inspection Information Inspection Date: 17 July 2020 Inspection Time: 02:30 pm Glossary of terms used and qualifications of Mark Dewhurst can be found at the bottom of this report document. Inspection Report 004764 The vehicle had a timing chain kit replaced under warranty at xxxxxxx Holden in June 2019, the vehicle’s engine warning has reappeared and a mechanic scanned the ECU and stated to the owner that the timing chain was stretched and faulty and was the cause of the engine warning message. The owner has commissioned this report to have the timing chain kit replaced again at no cost from the Holden dealer as it is now out of vehicle warranty. INSPECTION DETAILS On the 17th of July 2020 the vehicle Holden Commodore VE V6 was inspected by Mark Dewhurst, the ECU was scanned using a GScan2 to find DTC codes in both ECU and EBCM The EBCM was scanned first as the vehicle was not being inspected for a brake fault or had any brake faults messages on the dash LCD, the fault was C0561 an invalid CAN-Bus data code This type of code can be from many reasons from Low voltage at some point to any number of modules that communicate through the CAN-Bus system disrupting the data exchange, code saved and cleared to find didn’t return. Engine ECU scanned to find 2 faults P2176 and P0335, P2176 relates to the Throttle body position not learned, code saved and cleared and then as this procedure can be completed by this scanner a relearn was completed and a successful response received from the ECU, after rescanning found DTC returned possibly faulty throttle body P0335 relates to Crankshaft Position sensor malfunction as determined by the ECU, code saved and cleared and didn’t return. An inspection of the ECU live data shows that the engine rpm was correct at time of inspection and that the timing coalition angle was within .2 degrees meaning the ECU had determined that the timing chain was not faulty, stretched and was correct. There was also no audible sound of the timing chain noise at engine start up or while it was idling Attached Items Conclusion The vehicle has no evidence of chain failure or cam timing being incorrect and the fault codes are most likely due to a faulty crank sensor and throttle body fault. This is from evidence from the scanner connected to the vehicle and expert opinion as the vehicle’s engine was not dismantled to check the timing chain tension and free length or the timing marks. This report signed 17th of July 2020 Mark Dewhurst Qualification of Mark Dewhurst Advanced Diploma of Mechanical Engineering NSW VSCCS Certifier Engineering Signatory Certificate IV in Automotive Mechanical Diagnosis Motor Mechanic & Auto Electrician Blue, Pink & Gas Rego Inspections Automotive Air-conditioning Workshop & Mobile Service References None. Glossary ECU = Engine Control Unit DTC = Diagnostic Trouble Code EBCM = Electronic Brake Control Module LCD = Liquid Crystal Display CAN-Bus = Controller Area Network vehicle communication between microcontrollers report004764.pdf
  10. Version 1.0.0

    2 downloads

    Is your bull bar legal? Bull bars used in NSW must comply with the Technical Specification: Requirements for vehicle frontal protection systems fitted to light vehicles (PDF, 2.1Mb) Reference to this Technical Specification is now included in Schedule Two of the Road Transport (Vehicle Registration) Regulation 2017 creating a clear and ongoing regulatory framework for the safe use of bull bars in NSW. Clear requirements for safe bull bar use in NSW From 16 September, the Technical Specification (previously referred to as Bull Bar Tolerances and Conditions) will continue to provide clear and consistent guidance to motorists and industry stakeholders to help ensure that any bull bar that they purchase, sell, install or manufacture for sale is permitted under NSW regulations. The Technical Specification will also ensure vehicles meet other applicable standards affected by the bull bar, such as ground clearance, width, obscured lights and number plates, and the driver’s view of the road. There are no major changes This Technical Specification replaces, on an ongoing basis, previous requirements that have been in place since 2014 under a series of Ministerial Exemption Orders. It will be ‘business as usual’ as making the Technical Specification permanent does not result in material changes for motorists and industry stakeholders. Please note a bull bar is a type of Vehicle Frontal Protection System (VFPS). VFPS is the term used in the Regulation to encompass bull bars, nudge bars and similar devices fitted to the front of a vehicle. The main requirements contained in the Technical Specification are summarised in Is your bull bar legal? (PDF, 906Kb)

    Free

  11. Mark Dewhurst

    VSI 5

    Version 1.0.0

    37 downloads

    Light vehicle dimension limits This Vehicle Standards Information (VSI) No. 5 is intended as a guide to the dimension limits applicable to road vehicles not exceeding 4.5 tonnes gross vehicle mass (GVM) or aggregate trailer mass (ATM), that may be registered for use on NSW roads and road-related areas.

    Free

  12. Mark Dewhurst

    VSI 6

    Version 1.0.0

    9 downloads

    Light vehicle modifications A guide to modifications requiring certification under the Vehicle Safety Compliance Certification Scheme This Vehicle Standards Information (VSI) No. 6 is intended to help vehicle owners and modifiers determine what modifications to vehicles up to and including 4.5 tonnes gross vehicle mass require certification.

    Free

  13. Dynamic Road Tests shows practical demonstrations of the tests needed to assess vehicle braking system modifications.
  14. Brake Modifications – Overview supports the main steps of the different methods and regulations for assessing vehicle braking system modifications.
×
×
